Product Summary

The IT8512E/IX-L is a highly integrated, embedded controller with an embedded micro controller and integrated advanced functions. It is targeted for a wide range of portable application that uses the Low Pin Count (LPC) interface. The IT8512E/IX-L incorporates an 8032 micro controller which is an 8051-compatible, based on RISC architecture. The IT8512E/IX-L provides ACPI embedded controller function, keyboard controller (KBC) and matrix scan, PWM, DAC, ADC and SmartAuto Fan control for hardware monitor, PS/2 interface for external keyboard/mouse devices, system wake up functions for system power management, Watchdog timers, timers and general purpose I/O(GPIO), Consumer IR and SPI flash . It also supports the external flash shared by the host and EC side.

Features

IT8512E/IX-L features: (1)8032TT Embedded Controller; (2)LPC Bus Interface; (3)External SPI Flash Interface ; (4)Consumer IR ; (5)SM Bus Controller; (6)System Wake Up Control; (7)EC Wake Up Control; (8)Interrupt Controller; (9)Timer / Watch Dog Timer; (10)UART ; (11)ACPI Power Management Channel ; (12)GPIO; (13)KBC Interface; (14)ADC ; (15)DAC ; (16)PWM with SmartAuto Fan Control ; (17)PS/2 Interface; (18)KB Matrix Scan; (19)Power Consumption ; (20)128-pin LQFP/QFP/TFBGA.
