Product Summary

The RPGA988A is a TE connectivity surface mount rPGA socket. It is designed for use with Intel’s Core i7 989 and 988 mobile processors. The RPGA988A is designed for notebook motherboards that require a low profile surface mount interconnect. A simple screw cam is used to secure the package in place. The RPGA988A is validated to Intel’s design guides for high performance and extreme mobile products. It is used in Notebook Computers.

Parametrics

RPGA988A specifications: (1)Insulation Resistance : 800 megohms min at 500 VDC; (2)Temperature rating: Continuous 0 to 85℃, Operating -25 to 100℃; (3)Durability: 30 cycles; (4)Cam operation torque to mate or unmate package: 0.57N-m max.

Features

RPGA988A features: (1)989 or 988 contact positions on a 1.0 mm × 1.0 mm grid; (2)Simple cam screw actuation; (3)Solder balls facilitate surface mount to PCB; (4)Meets Intel validation; (5)Socket is supplied with a cap for vacuum pick and place.

Diagrams

RPGA988A dimensions

RPGAP000
RPGAP000

ZCG ZCH ADAPTER
Data Sheet
